Fishplates & Fixings / Wholesale & project supply
Fishplates, pale bolts and rail fixings for one standard 17-pale bay.
Palisade bay fixing kit components
Gallery includes component views and matching system references. Connection details are confirmed on the order drawing.
At a glance
Add the details you know. Our team can help with the rest.
Product and selected options included in your enquiry.
Technical details
| Supply unit | One fixing kit per standard 17-pale bay |
|---|---|
| Fishplates | 2, with their fixings |
| Pale bolts | 34 × M8 W-section bolts |
| Pale nuts | 34 × M8 snap-off nuts |
| Rail bolts | 4 × M12 bolts |
| Rail nuts | 4 × M12 snap-off nuts |
| Nominal kit weight | 1.3 kg |
| Finish | Galvanised |
| Bolt lengths and grades | Confirmed against the agreed connection drawing |
The product
KUNYU manufactures palisade bay fixing kits for fencing distributors, installers and project buyers. A galvanised fixing pack for one standard 17-pale fencing bay, including fishplates, M8 pale fixings and M12 rail fixings.
Prepare your enquiry
The listed pack is for a standard bay with 17 W-section pales and two rails. End runs, corners and gates may require additional or different connection plates; submit the full layout for a matched fixing schedule.
Confirm bolt length, thread, grade and mating holes for replacement work. Use new snap-off nuts when reassembling a connection.
Send the quantity, rail and post profile, hole centres and destination. We confirm the production drawing, packing and lead time with the quotation.
Ordering for a UK distributor or project? Review complete palisade fencing supplies and UK bulk quotation requirements to coordinate this product with matching components, packing and delivery scope.
Send your specification, quantity and destination.
Prepare a product enquiryBuyer questions
No. It contains the listed fishplates and fixings. Pales, rails and posts are ordered separately or as a complete fencing bay.
Compatibility must be checked against the system drawing. The listed quantities describe the standard 17-pale bay; other systems may use different connections.
