Posts & Fixings / Wholesale & project supply
Match posts and fixing sets to the selected twin-wire panel, mounting method and site layout. Confirm dimensions before ordering replacement components.
Twin-wire panel, rectangular post and two clip connections; close-up reference.
Photographs illustrate product configurations and connection details; they are not presented as KUNYU customer projects.
At a glance
Add the details you know. Our team can help with the rest.
Product and selected options included in your enquiry.
Technical details
Nominal reference configurations for quotation. The order specification and approved drawing confirm dimensions, tolerances, coating and the complete supply scope.
| Component scope | Line, corner and end posts; clips or clamp bars; post caps and matched fasteners. |
|---|---|
| Panel interface | 656 or 868 flat twin-wire mesh, nominal 200 × 50 mm mesh. |
| Post section reference | 60 × 60 mm square hollow section. |
| Wall thickness reference | 2.0 mm in a published 868 system; confirm the required wall and section for the project. |
| Fixing reference | M8 security fasteners occur in a published clip system; bolt length, grade and hole positions must match the assembly. |
| Mounting | Dig-in / embedded or base-plated; base plate, anchors and foundation are drawing-specific. |
| Post length and centres | Scheduled separately from panel height and width; confirm embedment or base-plate geometry. |
| Panel retention | Individual clips or full-length clamp bars, matched to the post and panel. |
| Gate-post interface | Gate posts are a separate design item and must not be substituted with ordinary line posts. |
| Surface treatment | Galvanised or galvanised + polyester powder coating; agree the galvanising sequence and coating requirements. |
| Colour references | RAL 6005 green / RAL 7016 anthracite / RAL 9005 black; other colours by enquiry. |
| Component | Reference / selection | Required detail |
|---|---|---|
| Line posts | 60 × 60 × 2.0 mm reference | Length; fixing holes; mounting; loading |
| Corner / end posts | Section to layout | Corner angle; termination and connection positions |
| Clips / clamp bars | To selected 656 / 868 system | Profile; length; thickness; hole centres |
| Fasteners | M8 clip-system reference | Thread; length; grade; nut or insert arrangement |
| Caps / base plates | Matched to actual post | Cap fit; plate size/thickness; anchor arrangement |
The section and fastener figures are quotation references, not a universal installation design. Compatibility with existing or third-party systems must be checked against the actual dimensions.
The product
A component enquiry needs more than the panel name. Send panel dimensions, the existing post or fixing drawing, photographs of the interface and the quantities required. For new installations, specify line, corner and end positions and the mounting method. For replacements, confirm post section, hole spacing, clamp geometry and fastener dimensions. Compatibility should be checked against the actual assembly. Gate posts and tall fence posts require their own design review rather than being treated as ordinary line posts.
Prepare your enquiry
New fence installation; matching system orders; approved replacement components. Select the final system against the site specification and installation design.
A component enquiry needs more than the panel name. Send panel dimensions, the existing post or fixing drawing, photographs of the interface and the quantities required. For new installations, specify line, corner and end positions and the mounting method. For replacements, confirm post section, hole spacing, clamp geometry and fastener dimensions. Compatibility should be checked against the actual assembly. Gate posts and tall fence posts require their own design review rather than being treated as ordinary line posts.
Packing quantities, order minimum, lead time, trade terms and payment terms are confirmed in the quotation after the specification and destination are reviewed. Panel bundles, post bundles, gate frames and small fixing packs should have separate counts and package identification.
| Order unit | Panels, posts, fixing sets or gate sets as listed in the quotation. |
|---|---|
| MOQ & lead time | Confirmed for the selected specification, quantity and production schedule. |
| Packing | Agree pallet or frame protection, separators, strapping and package labels before dispatch. |
| Packing quantities & weights | Confirmed from the actual supplied dimensions and packing schedule. |
| Commercial terms | Currency, trade term, named delivery place and payment terms stated in the quotation. |
| Inspection | Agree dimensional, wire, weld, finish and packing checks for the order. |
Send your specification, quantity and destination.
Prepare a product enquiryBuyer questions
Compatibility is not assumed. Confirm the post section, hole centres, clamp profile, panel wire schedule and bolt dimensions from the actual assembly before ordering.
No. The 60 × 60 × 2.0 mm section is one published system reference. Height, loading, mounting, site conditions and gate interfaces can require a different design.
Use the approved panel and post drawing to identify fixing locations. Counts change with panel height, post position, corner details and the chosen clip or clamp-bar system.
Send the product and quantity, destination country or port, selected finish and the relevant panel or gate schedule. Include project drawings, required inspection scope and the target delivery date.
Panel, post, gate and fixing quantities are reviewed separately. The quotation records packing protection, package identification, net and gross weights, commercial terms and the production schedule for the agreed specification.
Complete systemPlan a matched perimeter package with 656 or 868 panels, posts, fixings and gate requirements coordinated around your fence layout.
656A flat twin-wire panel specification with two nominal 6 mm horizontal wires and one 5 mm vertical wire. Request a panel-only quotation by size and finish.
868A flat twin-wire panel specification using two nominal 8 mm horizontal wires and one 6 mm vertical wire for projects that specify the 868 wire schedule.
